Gibson Memphis ES-335 Studio Single Pickup Ebony 2013 BRUGT

Product Image

DKK 13495

Woodstock Guitars


Ever since its introduction in 1958 Gibson’s legendary ES-335 has been hailed as one of the most versatile electric guitars ever produced, adept at everything from jazz, to country, to blues, to heavy rock. This ES-335 Studio, though, lives for one purpose: to rock your world like no other semi-hollow electric guitar ever.

While it retains the classic design elements and full build quality of the finest ES-335s, the ES-335 Studio from Gibson’s Memphis division strips away anything superfluous to focus like a laser on cranking out bone-crunching rock tone. This guitar has the same instantly familiar thinline, double-cutaway body styling from Gibson guitars seen in the hands of Eric Clapton, B.B. King, Alvin Lee and countless others, but the f-holes are eliminated to create a sleek looking top that is also more resistant to feedback. The electronics have been pared down to a single, super-hot Dirty Fingers Plus humbucking pickup in the bridge position, along with a single volume and tone pot. What more do you need to rock? Nothing—as the ES-335 Studio quickly proves, with the unparalleled playability that only a Gibson offers.

Equally hot-rodded looks are assured by the genuine smooth-satin nitrocellulose lacquer, paired with black hardware, tortoiseshell truss-rod cover and neck-joint cover, and a black Corian™ nut.

Body and Neck
The ES-335 Studio is constructed in the image of the original 335s of the late 1950s, with a semi-hollow body made from laminated maple with a bound Grade-AAA top layer and a solid maple center block, but without the traditional f-holes. The result is the perfect marriage of the traditional archtop’s looks and sonic depth, with the solidbody’s sustain and resistance to feedback. The neck is made from solid quarter-sawn mahogany, and topped with an unbound fingerboard made from baked maple, inlaid with simple pearloid dot position markers.

Pickups and Electronics
The ES-335 Studio is loaded with a single Dirty Fingers Plus humbucker, one of Gibson’s hottest pickups. For unbridled crunch and wailing lead tones, all with singing sustain, this pickup was born to rock out—yet it boasts surprising clarity for mellower moments. A single volume and tone control keep it simple.

Hardware and Plastics
The ES-335 Studio carries Gibson’s legendary Tune-o-matic bridge with and trapeze tailpiece, as well as high-quality Grover™ Rotomatic® tuners, all in black chrome. There’s no pickguard, but a tortoiseshell truss-rod cover and neck-joint cover lend an alternative touch of class.


Semi-hollow body made from laminated maple
Torrified Maple fingerboard with Pearloid dot inlays
Dirty Fingers Plus Humbucking Pickup in the bridge position
Black Chrome ABR-1 bridge and Trapeze Tailpiece
Black Chrome Grover® Rotomatics with 14:1 tuning ratio


Top: 3ply – Maple/Poplar/Maple
Body Type: Double Chamber, Semi-Hollow
Back: 3ply- Maple/Poplar/Maple

Species: Mahogany
Truss Rod: Traditional
Joint Angle: 4° (+/- 15 seconds)

Neck Fit
Joint: Mortise & Tenon
Cover: Tortoise Shell Neck Joint Cover
Joint Angle: Tolerance +/- .005″

Species: Baked Maple
Radius: 12″
Nut/E.O.B: 1.687/2.062
Inlays: Pearloid Dot
Binding: .075″
Other: Standard Fret Wire/Black Plastic Side Dots

Material: Black Corian
Width: 1.687
Slots: Gibson PLEK System

Logo: Gold ‘Gibson’ Logo Decal
Truss Rod Cover: Tortoise Shell Truss Rod Cover
Angle: 17 Degrees

Model: Grover™ Rotomatic®
Plating: Black Chrome
Tuning Ratio: 14:01

Type: Tune-O-Matic
Material: Zinc Die Cast Alloy
Plating: Black Chrome

Type: Stop Bar
Plating: Black Chrome
Knobs: Black Top Hats
Pickup Mounting Rings: Black Plastic
Strings: .010 – .046,
Strap Buttons: Aluminum End Pins

Bridge Position: Dirty Finger Plus (Ceramic)

Potentiometers: 1 Volume Control, 1 Tone Control
Type: 500k Audio Taper
Output Jack: 1/4″ Switchcraft

Sealer: Nitrocellulose Lacquer, Ebony
