Radial JDV Class A DI Box

Product Image

DKK 3500

Woodstock Guitars

The Radial JDV™ is a premium active direct box and preamp that features two inputs that can handle almost any source, from active and passive instruments, to microphones and piezo transducers.

  • 100% discrete class-A active direct box
  • Combine instrument and microphone inputs and phase-align
  • Drag Control load correction for natural tone
  • Huge 30-Volt rails for exceptional headroom

The Radial JDV Super DI redefines the direct box by introducing three zones; two selectable inputs, three instrument outputs, a tuner out and a balanced output for the console. These zones allow the musician to work within his own unique environment to spur on the creative process with new sounds, while providing the engineer with the ultimate in sonic performance.

Open up the JDV and you will find 100% discreet, ove-sized components (no op-amps). The JDV combines our unique feed-forward Class-A circuit (no feedback loops) with extraordinary 30-Volt internal rails to produce unmatched sonic performance where maximum headroom, ultra-low harmonic, phase and intermodulation distortion is achieved. The result is significantly greater detail, minimal coloration, and improved depth and spectral imaging. To capture the natural essence of the instrument, the JDV is equipped with Drag™ control, a unique load correction circuit that reintroduces the natural tone that is lost when connecting to buffered circuits. A pad on the output ensures the JDV will not overload your mixer. As a unity gain device, the JDV will accept huge input levels and send them through without restriction.

The JDV’s ultra-low noise signal path makes it possible to present an instrument with an unprecedented 3.9 Meg-Ohm input for use with the more demanding piezo pickups. The Radial JDV is without question the finest studio direct box made today.
